New York Slim Modular Chiller

Model# CMY

In a city where space is at a premium, the ChillMaster New York Slim Modular Chiller (Model# CMY) is redefining what’s possible. Designed in collaboration with engineers and service professionals, this innovative chiller is tailored to meet the unique challenges of New York City’s buildings.

At just 24 inches wide, the CMY is our most compact modular chiller yet. Its slim design allows it to navigate tight corners, fit into elevators, and pass through narrow access doors with ease—making installation in even the most space-constrained buildings a breeze.

With the ChillMaster CMY, you’re not just solving a problem—you’re investing in a solution built for the city.

Tonnages: 10-, 15-, 20-, and 30-Ton Modules

Configurations: 10-300 tons per bank

Voltages: 208, 230, 380, 460, 575

• Leaving water temperatures of 40°F with standard evaporator

• R410a and R454b refrigerant available

• Ultra slim, 24″ wide frame designed for small spaces

• Single and dual pumps racks available

• Intuitive, factory installed microprocessor-based controller compatible with BACnet® MSTP or IP

• Acoustic hoods and sound isolating cabinets available for sound sensitive applications

Nominal Tonnage	Width	Depth	Height	Weight
10-Ton	24 in [609.6 mm]	66 in [1676.4 mm]	64 in [1625.6 mm]	883 lbs [400.5 kg]
15-Ton	24 in [609.6 mm]	66 in [1676.4 mm]	64 in [1625.6 mm]	903 lbs [409.6 kg]
20-Ton	34 in [863.6 mm]	78 in [1981.2 mm]	72 in [1828.8 mm]	1139 lbs [516.6 kg]
30-Ton	34 in [863.6 mm]	78 in [1981.2 mm]	72 in [1828.8 mm]	1174 lbs [532.5 kg]
